Application

1.Product Description:

Polyphenylene sulfide (PPS) is a new type of high performance thermoplastic polymer with excellent high temperature resistance, corrosion resistance, radiation resistance, flame retardant, balanced mechanical properties, excellent dimensional stability and excellent electrical properties. Due to such excellent performance, PPS composite materials have replaced some metals as structural materials, and are widely used in electronic appliances, automobiles, machinery and chemical engineering, aerospace, military weapons and other fields.
1, Excellent heat resistance, continuous use temperature up to 220-240 ° C, glass fiber reinforced heat distortion temperature above 260 ° C
2, Good flame retardant and can be UL94-V0 and 5-VA (no dripping) without adding any flame retardant additives.
3, Excellent chemical resistance, only second to PTFE, almost insoluble in any organic solvent
4, PPS resin is highly reinforced by glass fiber or carbon fiber and has high mechanical strength, rigidity and creep resistance. It can replace part of metal as structural material.
The resin has excellent dimensional stability.
5,Extremly small molding shrinkage rate, and low water absorption rate. It can be used under high temperature or high humidity conditions.
6, Good fluidity. It can be injection molded into complex and thin-walled parts.


2.Product Parameters
Properties Test Condition Test Method Unit Typical Value
Physical
Specific Gravity   ASTM D792 - 1.65
Molding Shrinkage (Flow), 3.2mm   ASTM D955 % 0.1 ~ 0.2
Water Absorption 23oC, 24hrs ASTM D570 % < 0.02
Mechanical
Tensile Strength, 3.2mm   ASTM D638
@ Break 5mm/min   MPa 175
Tensile Elongation, 3.2mm   ASTM D638
@ Break 5mm/min   % 1~2
Flexural Strength, 3.2mm 1.3mm/min ASTM D790 MPa 250
Flexural Modulus, 3.2mm 1.3mm/min ASTM D790 GPa 13.5
IZOD Impact Strength, 3.2mm   ASTM D256
(Notched) 23oC   J/m 85
Rockwell Hardness R-Scale ASTM D785 - 110
Thermal
Heat Deflection Temperature, 6.4mm   ASTM D648
(Unannealed) 18.6kg   oC 265

Flammability   UL94 class
0.75mm     class V-0
Electrical
Comparative Tracking Index(CTI) Solution A IEC 60112 Volts -
Volume Resistivity 23oC ASTM D257 Ohm·m ≥ 1013
Dielectric Strength, 1mm 23oC ASTM D149 kV/mm 20

3.Company Profile
Hebei Chijiang Import and Export Co., LTDstarting from 2010,  is constantly engaged in the production of plastic raw materials products,which is located in Handan City, Hebei Province, China, covering 500 acres, having more than 350 employees. The main products are carbon black ,masterbatch, modified(pvc, PP, pa6, pa66, pbt, abs),Filler masterbatch,fireretardant,antioxidant,flexibilizer,plasticizer, and other plastic raw material(ldpe hdpe lldpe pvc pva pbt eva abs eps gpps hips pc pet etc.  With years of hard work and development, we have achieved a certain scale with technical service team for users with high quality and professional service.

4.Packaging & Shipping

1.Packing:
Water-Proof Paper Plastic Bag
20mt/20'FCL
2.Storage:
The resin should be stored in a drafty, dry warehouse and away from fire and direct sunlight. It should not be piled up in the open air.
3.Transportation:

During transportation, the product should not be exposed to strong sunlight or rain and should not be transported together with sand, soil, scrap metal, coal or glass. Transportation together with toxic, corrosive and flammable substance is strictly prohibited.

Quality:
And we are the manufactory, so you don’t need to doubt the quality.
Payment method: for example T/T, D/A, L/C, Westerm Union,other
1)We will ship the goods within 5days after get your payments.If you want to cancel or change order, please tell me within 24hours after you finish the payment…So we both can make the best of the bad bargain.
2)We will ship the goods that you order from us by HKEMS, DHL, UPS, TNT and EUB.We will decided to choose which courier depend on different countries.To find the best way to delivery the goods for you.
3)As usual you can get the goods with in 4-7days.If the goods were lost or not received for other reasons, please contact us immediately.
